Руководство пользователя электронного замка Hugolog HU01-SNL

1. Продукт закончилсяview

The Hugolog HU01-SNL Electronic Deadbolt Lock provides secure and convenient keyless entry for your home. This manual guides you through the installation, operation, and programming of your new lock.

Figure 1: Hugolog HU01-SNL Electronic Deadbolt Lock

1.1 Основные характеристики

• Keyless Entry Convenience: Unlock with a keypad, eliminating the need for physical keys. Features an auto-lock function with a programmable timer for added peace of mind.
• Auto-Lock & Anti-Peep Security: Programmable auto-lock timer from 10-99 seconds. Supports anti-peep functionality to prevent code exposure.
• Простая установка: Designed to fit doors 35-50mm thick and compatible with standard backsets and handle sizes. Self-adjusting for bolt side distance.
• Manage Access with Codes: Supports up to 20 user codes and single-use temporary codes, allowing flexible access management for family or guests.

1.2 Содержимое упаковки

Рисунок 2: Содержимое упаковки

The package includes the exterior assembly, interior assembly, latch, strike, mounting plate, installation guide, drilling template, mounting plate screws, strike screws, latch screws, cover screws, reset tool, backup key, and an optional bolt faceplate.

1.3 Характеристики

2. Настройка и установка

2.1 Проверки перед установкой

Before beginning installation, ensure your door is prepared and meets the following dimensions:

• Door Hole: 2-1/8 inches (54 mm)
• Backset: 2-3/8 inches (60 mm) or 2-3/4 inches (70 mm)
• Door Edge Hole: 1 inch (25 mm)
• Door Thickness: 1-3/8 inches to 2 inches (35 to 50 mm)

Figure 3: Door Preparation and Dimensions

2.2 Пошаговая установка

Follow these steps to install your Hugolog electronic deadbolt lock:

1. Установите защелку: Ensure the latch is oriented correctly (facing upwards) and install it into the door frame. Secure it with two screws. Test the deadbolt's smooth operation with a screwdriver and keep the latch in the retracted (unlocked) position.
2. Установите внешнюю сборку: Hold the exterior assembly flush against the door. Guide the key tailpiece and power cable through the door hole.
3. Установите монтажную пластину: Install the mounting plate, ensuring it is parallel to the door edge. Secure it with the provided screws.
4. Сборка внутренней проводки: Connect the power cable from the exterior assembly to the socket on the interior PCB. Rotate the thumb turn to a vertical, upward-facing position.
5. Fix Interior Assembly: Fix the interior assembly to the mounting plate. Test if the latch works smoothly by rotating the thumb turn.
6. Insert Batteries and Reset: With the lock in the unlocked state, insert three new AA alkaline batteries into the battery pack. Use the reset tool to press and hold the reset hole for 3 seconds until you hear a beep. The deadbolt will then reallocate to learn the door's orientation.
7. Полная установка: Put back the lid of the battery pack. Test the lock's functionality using the backup key and the default master pin code (12345678).

Рисунок 4: Простые шаги установки

3. Инструкция по эксплуатации

3.1 Unlocking and Locking

The Hugolog deadbolt offers multiple ways to unlock and lock your door:

• Клавиатура: Enter your programmed user code or master code on the keypad.
• Физический ключ: Use the provided backup key for manual unlocking.
• Поворот большого пальца: Вручную заблокируйте или разблокируйте засов изнутри с помощью поворотной ручки.

Рисунок 5: Несколько способов разблокировки

3.2 Multi-Function Button (MFB) Usage

The button with the Hugolog logo on the keypad is the Multi-Function Button (MFB). It is used for entering administrator mode and confirming operations.

4. Руководство по программированию

All pin codes must be 4-10 digits long. Avoid forward/backward number sequences or repeating number sequences for security. Existing code sequences are also invalid.

4.1 Изменить мастер-код

The default master pin code is [12345678]. You will be prompted to change this code before adding any other codes for security reasons.

1. Дважды нажмите кнопку MFB.
2. Введите текущий мастер-код.
3. Нажмите кнопку MFB.
4. Wait for long green lights, then press '1'.
5. Enter your New Master Code.
6. Нажмите кнопку MFB.
7. Re-enter your New Master Code to verify.
8. Press the MFB to store the new master code.

4.2 Add User Code

You can add up to 20 user codes.

1. Дважды нажмите кнопку MFB.
2. Введите мастер-код.
3. Нажмите кнопку MFB.
4. Wait for long green lights, then press '2'.
5. Введите новый код пользователя.
6. Нажмите кнопку MFB.
7. Re-enter the New User Code to verify.
8. Press the MFB to add the new user code.

4.3 Delete User Code

To delete an unwanted user code:

1. Дважды нажмите кнопку MFB.
2. Введите мастер-код.
3. Нажмите кнопку MFB.
4. Wait for long green lights, then press '3'.
5. Введите код пользователя, который необходимо удалить.
6. Press the MFB to delete the user code.

4.4 Тихий режим

Silent Mode disables all beeps and sounds from the lock. It is disabled by default.

1. To Enable Silent Mode: Double-press the MFB, enter Master Code, press MFB, wait for long green lights, then press '4', then '2', then MFB.
2. To Disable Silent Mode: Double-press the MFB, enter Master Code, press MFB, wait for long green lights, then press '4', then '1', then MFB.

4.5 Auto-Lock Time Delay

The auto-lock function automatically locks the door after a set period. The default delay is 30 seconds.

1. To Enable Auto-Lock: Double-press the MFB, enter Master Code, press MFB, wait for long green lights, then press '5', then '1', then MFB.
2. To Disable Auto-Lock: Double-press the MFB, enter Master Code, press MFB, wait for long green lights, then press '5', then '2', then MFB.
3. To Set Auto-Lock Time Delay (10-99 seconds): Double-press the MFB, enter Master Code, press MFB, wait for long green lights, then press '8', enter the desired delay time (e.g., '30' for 30 seconds), then MFB.

Figure 6: Auto-Lock for peace of mind

4.6 Add One-Time Code

A one-time code will expire after a single use.

1. Дважды нажмите кнопку MFB.
2. Введите мастер-код.
3. Нажмите кнопку MFB.
4. Wait for long green lights, then press '7'.
5. Enter the New One-Time Code.
6. Нажмите кнопку MFB.
7. Re-enter the New One-Time Code to verify.
8. Press the MFB to add the one-time code.

Figure 7: Managing Access with User Codes

4.7 Режим отпуска

In Vacation Mode, the lock will reject all user codes until the master code is entered. If the lock is unlocked by key or thumb turn while in Vacation Mode, an alarm will sound.

1. To Enable Vacation Mode: Double-press the MFB, enter Master Code, press MFB, wait for long green lights, then press '6', then MFB.
2. To Disable Vacation Mode: Введите мастер-код.

Figure 8: Anti-Peep Pin Code

5. Поиск Неисправностей

For common issues and solutions, please refer to the detailed troubleshooting section in the full user manual. If the problem persists or cannot be resolved, please contact customer support.

6. Гарантия и поддержка

Hugolog provides satisfactory service with no hidden fees. For technical support or warranty inquiries, please contact us directly.
